簡介

Featuring CorePower technology, Apacer’s SS220-CFast is a well-balanced CFast card with compact form factor and great performance. This new flash memory card comes with SATA 6.0 Gbps interface for higher performance and is compliant with standard SS220-CFast specifications. SS220-CFast 2.0 consists of SATA-based 7-pin signal segment and 17-pin for power and control purposes. It can offer moderate capacity and decent data transfer performance. For power efficiency, this new flash memory card leverages the technological benefits of SATA Revision 3.1 specifications, including Device Sleep. That will greatly reduce power consumption when the device is not in operating mode. For data integrity, the SS220-CFast card is built with ECC engine correcting up to 40-bit. Together with its small form factor nature, Apacer SS220-CFast 2.0 is definitely the ideal solution to replace conventional PATA-based CompactFlash for applications in industrial computing systems, mobile computers and video processing instruments.

參數

型號SS220-CFast

介面SATA 3.0 (6Gb/s)

接頭(7+17) pin male

板型CFast

NAND 顆粒SLC

容量8GB~64GB

外接DRAMYes

讀取速度(MB/sec)Up to 520

寫入速度(MB/sec)Up to 455

ECC偵錯功能Built-in 40-bit per 1K bytes BCH ECC

標準作業溫度(°C)0 ~ + 70

最高作業溫度(°C)-40 ~ + 85

儲存溫度(°C)-40 ~ + 100

H/W Write ProtectYes

沖擊耐力50G (complied with MIL-STD810)

震動耐力15G (complied with MIL-STD810)

電壓3.3 V ± 5%

用電量"Active mode: 570 mA & Idle mode: 75 mA

尺寸42.8 x 36.4 x 3.6 (mm)

MTBF (小時)>2,000,000

技術特點Page Mapping / 寬溫 / 熱傳感器 / S.M.A.R.T. / 擦除 / 寫保護

應用云計算 / 車載 / 嵌入式和IPC / 國防 / 游戲 / 保健
